Introduction

Amazon S3 Files mounts an S3 bucket as an NFS file system inside EC2, ECS Fargate, and Lambda — giving your applications a familiar POSIX file-system interface backed by durable object storage.

This site contains two types of walkthroughs:

• CLI — step-by-step AWS CLI commands for EC2 and Lambda. Each section is self-contained and includes its own setup and teardown.
• Terraform — terraform apply examples for EC2, ECS Fargate, and Lambda using the terraform-aws-s3-files modules.

---

Prerequisites

Review these requirements before starting any walkthrough. They apply to both the CLI and Terraform sections.

S3 bucket

Requirement	Detail
Versioning	Must be enabled — S3 Files uses versioning to synchronise changes between the file system and the bucket. File system creation fails if versioning is off.
Encryption	SSE-S3 (AES256) or SSE-KMS only. SSE-C (customer-provided keys) and DSSE-KMS are not supported. New buckets default to SSE-S3, which works without extra configuration.

IAM — two roles required

S3 Files uses exactly two IAM roles:

Role	Service principal	Purpose
File system role	elasticfilesystem.amazonaws.com	S3 Files assumes this role to read/write your bucket and manage EventBridge sync rules. The trust policy aws:SourceArn must use arn:aws:s3files:… — not arn:aws:elasticfilesystem:….
Compute role	ec2.amazonaws.com / ecs-tasks.amazonaws.com / lambda.amazonaws.com	Your compute resource assumes this role to mount the file system and read objects from S3.

Network

NFS port 2049 TCP must be open between the compute security group and the mount target security group. Mount targets run in the same VPC as your compute resources, one per Availability Zone.

AWS CLI (for CLI walkthroughs)

The aws s3files subcommand requires AWS CLI v2.34.26 or newer. Versions v2.34.23 and earlier do not include the s3files namespace and return Found invalid choice 's3files'. AWS CLI v1 (e.g. installed via pip install awscli) never includes S3 Files.

aws --version          # must show 2.34.26 or newer
aws s3files help       # must list s3files subcommands

Terraform (for Terraform walkthroughs)

Requirement	Minimum version
Terraform	1.5
AWS provider (hashicorp/aws)	6.40

Note

The Terraform AWS provider added native S3 Files resources (aws_s3files_*) in version 6.40. Earlier versions do not include these resources.

Platform constraints

Platform	Constraint
EC2	Requires amazon-efs-utils v3.0.0+ for the mount -t s3files helper
ECS	Fargate and Managed Instances only — EC2 launch type is not supported
Lambda	Access point required — Lambda cannot mount by file system ID alone

---

Choose a walkthrough

CLI — EC2 Full CLI walkthrough: bucket, file system, IAM, mount targets, security groups, launch instance, mount, verify, and teardown.

CLI — Lambda Full CLI walkthrough: bucket, file system, IAM, mount targets, security groups, access point, attach function, verify, and teardown.

Terraform Provision all S3 Files infrastructure and your compute resource with a single terraform apply. Examples for EC2, ECS Fargate, and Lambda.
