Query Pipeline

The query pipeline transforms a user question into a structured, sourced answer. It embeds the question, searches S3 Vectors S3 Vectors
Amazon S3 Vectors — a purpose-built vector storage capability within S3 that enables similarity search over embeddings without a separate vector database. for similar documents, reranks results using similarity and recency, builds a context window, and generates a response with Bedrock Bedrock
Amazon Bedrock — a fully managed service for accessing foundation models (embedding and LLM) via a unified API. .

Request Lifecycle

A complete query passes through six stages:

1. Embed — Convert the user question into a 1024-dimensional vector using Titan Embeddings V2 Titan Embeddings V2
   Amazon Titan Embeddings V2 — the Bedrock foundation model used to generate 1024-dimensional text embeddings.
2. Search — QueryVectors QueryVectors
   S3 Vectors QueryVectors API — finds the most similar vectors to a query vector using Top-K nearest neighbor search. from S3 Vectors with an over-fetched Top-K
3. Load — Retrieve full document bodies from S3 for each match
4. Rerank — Score candidates by 80% similarity + 20% recency, then select the best
5. Context — Assemble top snippets into a prompt context window
6. Generate — Invoke Claude via Bedrock to produce a structured answer

Adaptive Top-K Strategy

Rather than using a fixed Top-K Top-K
The number of nearest neighbor results returned by a vector similarity search query. value, the pipeline adapts how many vectors it retrieves based on the question type.

rag/query.py

MIN_TOP_K = 3
MAX_TOP_K = 8
RETRIEVAL_MULTIPLIER = 3

def _adaptive_top_k(question: str, requested_top_k: int) -> int:
    target = max(MIN_TOP_K, requested_top_k)
    if _extract_time_window_days(question) is not None:
        target = max(target, 6)
    elif _is_broad_query(question):
        target = max(target, 5)
    return min(target, MAX_TOP_K)

The function detects two patterns:

• Time-windowed queries (e.g., “last 2 weeks”) — bumps to at least 6 results
• Broad queries (e.g., “summarize recent updates”) — bumps to at least 5 results

Tip

The actual retrieval fetches desired_top_k × RETRIEVAL_MULTIPLIER vectors (capped at 20). This over-fetch ensures the reranking stage has enough candidates to choose from after filtering and deduplication.

Over-Fetch and Filter

The pipeline retrieves more vectors than it needs, then narrows down:

rag/query.py

desired_top_k = _adaptive_top_k(question, top_k)
retrieval_top_k = min(desired_top_k * RETRIEVAL_MULTIPLIER, 20)
time_window_days = _extract_time_window_days(question)
cutoff = (
    datetime.now(timezone.utc) - timedelta(days=time_window_days)
    if time_window_days else None
)

After retrieval, candidates are filtered:

1. Source validation — skip vectors with no source metadata
2. Time window — discard documents published before the cutoff date
3. Deduplication — remove duplicates by normalized URL or title

Reranking

Each surviving candidate receives a composite score combining cosine similarity cosine similarity
Cosine similarity — a distance metric that measures the angle between two vectors. Values range from 0 (opposite) to 1 (identical direction). Preferred for text embeddings. with a recency boost:

rag/query.py

RECENCY_HALF_LIFE_DAYS = 30.0

def _recency_score(published_dt: datetime | None) -> float:
    if published_dt is None:
        return 0.25
    age_days = max(
        (datetime.now(timezone.utc) - published_dt).total_seconds() / 86_400.0,
        0.0,
    )
    return math.exp(-age_days / RECENCY_HALF_LIFE_DAYS)

The final score formula:

final_score = (0.8 × similarity) + (0.2 × recency_score)

Note

Documents with no publish date receive a default recency score of 0.25 — roughly equivalent to a 42-day-old article. This prevents undated documents from being unfairly penalized or boosted.

Candidates are sorted by final score descending, then the top desired_top_k are selected.

Snippet Extraction

For each candidate, the pipeline extracts the most relevant paragraphs to use as context:

rag/query.py

def _best_snippet(body: str, question: str, max_chars: int = 700) -> str:
    paragraphs = [
        part.strip() for part in body.split("\n\n") if part.strip()
    ]
    question_terms = _tokenize(question)
    scored = []
    for paragraph in paragraphs:
        terms = _tokenize(paragraph)
        overlap = len(question_terms.intersection(terms))
        scored.append((overlap, len(paragraph), paragraph))
    scored.sort(key=lambda row: (row[0], row[1]), reverse=True)
    # Select paragraphs with highest term overlap
    ...

Paragraphs are ranked by term overlap with the question. The function greedily selects paragraphs until the 700-character budget is consumed, prioritizing those with the most keyword matches.

Context Window Building

The selected candidates are assembled into a structured context block for the LLM LLM
Large Language Model — Anthropic Claude accessed via Bedrock inference profile. Generates structured answers from retrieved context. :

rag/query.py

MAX_CONTEXT_CHARS = 8_000

def _build_context(candidates, max_chars=MAX_CONTEXT_CHARS):
    blocks = []
    total = 0
    for idx, candidate in enumerate(candidates, start=1):
        block = (
            f"[{idx}] Title: {candidate.source.title}\n"
            f"[{idx}] URL: {candidate.source.url}\n"
            f"[{idx}] Published: {candidate.source.published}\n"
            f"[{idx}] Feed: {candidate.source.feed}\n"
            f"[{idx}] Snippet:\n{candidate.snippet}\n"
        )
        if total + len(block) > max_chars:
            break
        blocks.append(block)
        total += len(block)
    return "\n---\n".join(blocks)

Each source is numbered [1], [2], etc., so the LLM can cite them in its response. The context is capped at 8,000 characters to stay within prompt budget.

Caution

If no candidates survive filtering (empty result set), the pipeline returns a structured fallback message explaining that no matching announcements were found — it never sends an empty context to the LLM.

LLM Generation

The final stage invokes Claude via Bedrock inference profile Bedrock inference profile
A Bedrock cross-region inference profile that routes requests to the nearest available region. Used for the LLM (au.anthropic.claude-sonnet-4-5-20250929-v1:0). with a structured prompt:

rag/query.py

def _bedrock_llm(client, model_id, context, question, source_count):
    body = {
        "anthropic_version": "bedrock-2023-05-31",
        "max_tokens": 1024,
        "messages": [{
            "role": "user",
            "content": (
                "You are an AWS news briefing assistant. "
                "Use only the provided context.\n"
                "If the context is insufficient, state that "
                "clearly and do not guess.\n\n"
                "Output markdown using this structure:\n"
                "## Direct answer\n## What is known\n"
                "## What is unclear\n## Sources used\n\n"
                f"There are {source_count} sources in context. "
                "Every factual bullet must cite at least one "
                f"source.\n\nContext:\n{context}\n\n"
                f"Question: {question}"
            ),
        }],
    }
    response = client.invoke_model(
        modelId=model_id, body=json.dumps(body), ...
    )

The prompt enforces:

• Grounding — use only the provided context, no guessing
• Structure — direct answer, known facts with citations, unclear items, sources used
• Citation — every factual bullet must reference at least one numbered source

Entry Point

The ask() function orchestrates the entire pipeline:

rag/query.py

def ask(config: Config, question: str, top_k: int = 3) -> QueryResult:
    """Run the full RAG query pipeline."""
    bedrock = boto3.client("bedrock-runtime", region_name=config.aws_region)
    s3vectors = boto3.client("s3vectors", region_name=config.aws_region)

    desired_top_k = _adaptive_top_k(question, top_k)
    retrieval_top_k = min(desired_top_k * RETRIEVAL_MULTIPLIER, 20)

    query_embedding = _bedrock_embed(bedrock, config.embedding_model_id, question)
    response = s3vectors.query_vectors(
        vectorBucketName=config.vector_bucket,
        indexName=config.vector_index,
        queryVector={"float32": query_embedding},
        topK=retrieval_top_k,
        returnMetadata=True,
    )
    # ... filter, rerank, build context, generate ...
    return QueryResult(question=question, answer=answer, sources=sources)

Tip

The ask() function is invoked by the Query Lambda handler. The Lambda receives a JWT-authenticated request via API Gateway, extracts the question, calls ask(), and returns the structured response.

Pipeline Parameters

Parameter	Value	Purpose
MIN_TOP_K	3	Minimum number of sources in final answer
MAX_TOP_K	8	Maximum sources regardless of query type
RETRIEVAL_MULTIPLIER	3	Over-fetch factor (retrieve 3× desired)
MAX_CONTEXT_CHARS	8,000	Maximum context window size for LLM prompt
RECENCY_HALF_LIFE_DAYS	30	Exponential decay half-life for recency scoring
Snippet max chars	700	Character budget per document snippet
max_tokens	1,024	Maximum LLM response length
